Making Naphthalene Crystals

I realized that time passes so fast, it was about a week since I made a new post. I feel like it has been for only 3 days. Anyways, let’s get started with the post.

I’ll try to make Naphthalene crystals. Naphthalene is a white crystalline solid with a characteristic odor. It’s melting point is about 80°C. If you leave it to expose air, it’ll change into a gas.

My Naphthalene:

IMG_20140101_070110

I put about 7 balls of Naphthalene into a 600 ml beaker, and I put a flask with cold water on top of it.

IMG_20140101_070626

IMG_20140101_070807

The Naphthalene is vaporizing quickly. The vapors will get in contact with the cold water in the flask and turn back into a solid.

Crystals are also forming in the beaker, because it’s touching the cold air outside, just like what’s happening in the flask.

IMG_20140101_071936

All of the Naphthalene has changed into liquid, it was boiling a little too fast so I stopped the heat.

IMG_20140101_072251

The crystals are so fragile so I used a trash bag to make the crystals fall onto it.

IMG_20140101_072408

Here are the crystals. They look like fern leaves and snowflakes! But I wish the crystals were chunks, not thin like this. I looked in the internet for pictures of Naphthalene crystals, and they’re just like mine. The reason that it’s yellow is because the light is just reflecting it.

Here’s the beaker:

IMG_20140101_072419

I hoped you enjoyed the post, if you did, drop a like down below ↓
